Product Model: S5735S-L48FT4S-A
Retail Price: US$597.00
Email Us To Get Special Price Today: [email protected]
S5735S-L24FT4S-A?is the Huawei S5735-L switch with 24 ?? 10/100Base-Tx ports, 24 ?? 10/100/1000Base-T ports,4 ?? GE SFP ports. Huawei CloudEngine S5735-L is a series of simplified gigabit access switches that provide 12?C48 flexible all-GE downlink ports and four fixed GE or 10 GE uplink ports. They are designed for enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and powered by Huawei??s Versatile Routing Platform (VRP), CloudEngine S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols ?? providing higher performance and more powerful service processing capabilities for networks.
Quick Spec
Table 1 shows the quick spec.
|
Product Model |
S5735S-L48FT4S-A |
|
Fixed Ports |
24 ?? 10/100Base-Tx ports, 24 ?? 10/100/1000Base-T ports,4 ?? GE SFP ports |
|
PoE+ |
Not Supported |
Supported Transceivers
Table 2 shows the recommended models.
|
Model |
Description |
|
OMXD30000 |
Huawei Optical Transceiver OMXD30000, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
|
SFP-GE-LX-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
|
OMXD30009 |
Transceiver, QSFP+, 1310nm, 41.25Gbps, -7dBm, 2.3dBm, -11.5dBm, LC, SMF, 10 |
|
ESFP-GE-SX-MM850 ? |
Optical Transceiver, eSFP, GE, Multi-mode Module (850nm,0.5km, LC) |
Compare to Similar Items
Table 3 shows the comparison.
|
Product Model |
S5735S-L48P4X-A |
S5735S-L48FT4S-A |
|
Fixed Ports |
48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports |
24 ?? 10/100Base-Tx ports, 24 ?? 10/100/1000Base-T ports,4 ?? GE SFP ports |
|
PoE+ |
Supported |
Not Supported |
Before Purchasing
Do you have any question about the S5735S-L48FT4S-A?
Contact us – Email Live Chat or [email protected].
S5735S-L48FT4S-A Datasheet
S5735S-L48FT4S-A Specification |
|
|
Memory (RAM) |
1 GB |
|
Flash |
512 MB in total. To view the available flash memory size, run the display version command. |
|
Mean time between failures (MTBF) |
50.68 years |
|
Mean time to repair (MTTR) |
2.37 hours |
|
Availability |
> 0.99999 |
|
Service port surge protection |
Common mode: ±7 kV |
|
Power supply surge protection |
±6 kV in differential mode, ±6 kV in common mode |
|
Dimensions (H x W x D) |
|
|
Stack ports |
Any 10/100/1000BASE-T ports or 1000BASE-X ports (applicable in V200R019C10 and later versions) |
|
RTC |
Not supported |
|
RPS |
Not supported |
|
PoE |
Not supported |
|
Rated voltage range |
|
|
Maximum voltage range |
|
|
Maximum power consumption (100% throughput, full speed of fans) |
44 W |
|
Typical power consumption (30% of traffic load)
|
30 W |
|
Operating temperature |
-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). |
|
Short-term operating temperature |
-5°C to +55°C (23°F to 131°F) at an altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The equipment can operate beyond the normal operating temperature range for a short-term period, but the following conditions must be met:
The equipment may be damaged or experience unexpected exceptions if any of the preceding limits is exceeded. The equipment cannot start when the temperature is lower than 0°C (32°F). The maximum distance of optical modules used in these conditions cannot exceed 10 km. |
|
Storage temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Noise under normal temperature (27°C, sound power) |
< 53.3 dB(A) |
|
Relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
0-5000 m (0-16404 ft.) |
|
Certification |
|
