Product Model: PWR-C2-250WAC=
Retail Price: US$259.00
Email Us To Get Special Price Today: [email protected]
PWR-C2-250WAC= is 250W AC Config 2 Power Supply Spare.
Quick Specs
Figure 1 shows the appearance of PWR-C2-250WAC=.
Table 1 shows the Quick Specs.
|
Product Code |
PWR-C2-250WAC= |
|
Power Supply Rated Maximum |
250W |
|
Total Output BTU (Note: 1000 BTU per hr = 293 W) |
853 BTU/hr, 250W |
|
Input-Voltage Range and Frequency (Note: ¡À10% of “Input-Voltage Range¡±) |
100-240VAC, 50-60 Hz |
|
Input Current |
4-2A |
|
Output Ratings |
12V @ 20.83A |
|
Output Holdup Time |
16.7 ms minimum @ 100VAC |
|
Power-Supply Input Receptacles |
IEC 320-C13 (IEC60320-C13) |
|
Power Cord Rating |
10A |
|
Physical Specifications |
(H x W x D): 1.58 X 3.75 X 11.75 in (4.0 x 9.5 x 29.8 cm) Weight: 2.55 lb (1.16 kg) |
The Modules, Cards, Licenses
Table 2 shows the recommended elements for the PWR-C2-250WAC=.
|
Category |
Model |
Description |
|
Power Cable |
CAB-TA-NA |
North America AC Type A Power Cable |
|
CAB-TA-JP |
Japan AC Type A Power Cable |
|
|
CAB-C15-CBN |
Cabinet Jumper Power Cord, 250 VAC 13A, C14-C15 Connectors |
|
|
CAB-C15-CBN-JP |
Japan Cabinet Jumper Power Cord, 250 VAC 12A, C14-C15 |
|
|
CAB-TA-SW |
Switzerland AC Type A Power Cable |
Compare to Similar Items
Table 3 shows the comparison of PWR-C2-250WAC=, PWR-C2-640WDC= and PWR-C2-1025WAC=.
|
Product Code |
PWR-C2-250WAC= |
PWR-C2-640WDC= |
PWR-C2-1025WAC= |
|
Power Supply Rated Maximum |
250W |
640W |
1025W |
|
Total Output BTU (Note: 1000 BTU per hr = 293 W) |
853 BTU/hr, 250W |
2188 BTU/hr, 640W |
3497 BTU/hr, 1025W |
|
Input-Voltage Range and Frequency (Note: ¡À10% of “Input-Voltage Range¡±) |
100-240VAC, 50-60 Hz |
-36VDC to -72VDC |
115-240VAC, 50-60 Hz |
|
Input Current |
4-2A |
21 – 10.5 A |
12-6A |
|
Output Ratings |
12V @ 20.83A |
12V @ 20.83A -54V @ 7.36A |
12V @ 20.83A -54V @ 14.6A |
|
Output Holdup Time |
16.7 ms minimum @ 100VAC |
> 2ms@-48VDC |
10 ms minimum @ 102.5VAC |
|
Power-Supply Input Receptacles |
IEC 320-C13 (IEC60320-C13) |
Terminal strip |
IEC 320-C16 (IEC60320-C16) |
|
Power Cord Rating |
10A |
20A @ 100VDC |
13A |
Before Purchasing
Do you have any question about the PWR-C2-250WAC=?
Contact us – Email Live Chat or [email protected].
PWR-C2-250WAC= Datasheet
PWR-C2-250 WAC= Specifications |
|
|
Power Supply Rated Maximum |
250W |
|
Total Output BTU (Note: 1000 BTU per hr = 293 W) |
853 BTU/hr, 250W |
|
Input-Voltage Range and Frequency (Note: ¡À10% of “Input-Voltage Range¡±) |
100-240VAC, 50-60 Hz |
|
Input Current |
4-2A |
|
Output Ratings |
12V @ 20.83A |
|
Output Holdup Time |
16.7 ms minimum @ 100VAC |
|
Power-Supply Input Receptacles |
IEC 320-C13 (IEC60320-C13) |
|
Power Cord Rating |
10A |
|
Physical Specifications |
(H x W x D): 1.58 X 3.75 X 11.75 in (4.0 x 9.5 x 29.8 cm) Weight: 2.55 lb (1.16 kg) |
|
Operating Temperature |
For the operating temperature ranges at various altitudes of AC and DC power supply module powered switches, see Table 1. |
|
Storage Temperature |
-40 to 158¡ãF (-40 to 70¡ãC) |
|
Relative Humidity Operating and Nonoperating Noncondensing |
5 to 96% noncondensing |
|
Altitude |
16,400 ft. (5,000 meters) |
|
MTBF |
Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Issue 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level). |
|
EMI and EMC Compliance |
¡°AC OK¡±: Input power to the power supply is OK ¡°PS OK¡±: Output power from the power supply is OK |
|
Safety Compliance |
For the operating temperature ranges at various altitudes of AC and DC power supply module powered switches, see Table 1. |
|
LED Indicators |
-40 to 158¡ãF (-40 to 70¡ãC) |
