Product Model: P25216-AA1 HPE DL388 Gen10 8SFF
Retail Price: US$6,055.00
Email Us To Get Special Price Today: [email protected]
HPE DL388 Gen10 4210R 1P 16G 8SFF Sever comes standard with an Intel Xeon-Silver 4210R (2.4GHz/10-core/100W) processor, 16G memory, P408i-a, 8SFF, and 800W power supply. HPE ProLiant DL388 Server delivers the best performance and expandability in the HPE 2P rack portfolio.Reliability, serviceability and near continuous availability, backed by a comprehensive warranty, make it ideal for any environment – P25216-AA1 server.
Quick Spec
Table 1 shows the quick spec.
|
Part Number |
P25216-AA1 |
|
Model |
HPE Proliant DL388 G10 4210R (10-Core, 2.4 GHz, 100W) 1P 16G P408i-a NC 8SFF 800W PS server |
|
Processor |
Intel Xeon Silver 4210R Processor (2.4GHz/10-core/100W) |
|
Memory |
16G |
|
Array controller |
Built-in HPE Smart Array P408i-a |
|
PCIe slots |
3 |
|
Hard Drive |
8 SFF |
|
Power Supply |
800W |
|
Height |
2U |
Product Details
Figure 1 shows the SFF front panel components.
Note:
|
① |
Box 1 (optional drives or universal media bay, see figure 2) |
③ |
Box 3 Drives 1-8 |
⑤ |
USB 3.0 port |
|
② |
Box 2 (optional drives) |
④ |
Serial label pull tab or optional Systems Insight Display |
⑥ |
iLO service port |
Figure 2 shows the Universal media bay components. It needs to be purchased separately.
Note:
|
① |
② |
③ |
④ |
⑤ |
|
USB 2.0 port |
Video display port |
Optical disk drive (optional) |
USB 2.0 port |
Drives (optional) |
Figure 3 shows the rear panel components. These installed drives need to be purchased separately.
Note：
|
① |
Primary riser slots 1-3 (Optional drive cage) |
⑤ |
Power supply 2 |
⑨ |
iLO management port |
|
② |
Optional riser slots 4-6 (Optional drive cage) |
⑥ |
Video port |
⑩ |
USB 3.0 ports |
|
③ |
Optional riser slots 7-8 (Optional drive cage) |
⑦ |
Serial port (optional)* |
FlexibleLOM slot |
|
|
④ |
Power supply 1 |
⑧ |
1Gb RJ-45 ports 1–4 |
||
*When a tertiary riser cage is installed as shown, the serial port can be installed in riser slot 6.
Supported Hard Drives
Table 2 shows the supported SFF hard drives.
|
Part Number |
Description |
|
872479-B21 |
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) Sc 3yr Wty Digitally Signed Firmware HDD |
|
872481-B21 |
HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD |
|
870759-B21 |
HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Ds Digitally Signed Firmware HDD |
|
881457-B21 |
HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD |
|
870757-B21 |
HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
P04556-B21 |
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
P04560-B21 |
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
P04564-B21 |
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
P04566-B21 |
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
P04556-B21 |
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
P04560-B21 |
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
Compare to Similar Item
Table 3 shows the comparison.
|
Part Number |
P25216-AA1 |
868709-AA1 |
|
Model |
HPE Proliant DL388 G10 4210R (10-Core, 2.4 GHz, 100W) 1P 16G P408i-a NC 8SFF 800W PS server |
HPE ProLiant DL388 Gen10 3104 1.7GHz 6C 85W 1P 16G-2R S100i 8SFF 1x500W Entry CN Server |
|
Processor |
Intel Xeon Silver 4210R Processor (2.4GHz/10-core/100W) |
Intel Xeon-Bronze 3104 (1.7GHz/6-core/85W) processor |
|
Memory |
16G |
16G-2R |
|
PCIe slots |
3 |
3 |
|
Hard Drive |
8 SFF |
8 SFF |
|
Power Supply |
800W |
500W |
Table 4 shows the HPE DL388 vs Dell R740.
|
Series |
HPE ProLiant DL388 Gen10 |
HPE ProLiant DL388 Gen10 |
HPE ProLiant DL388 Gen10 |
Dell EMC PowerEdge R740 |
|
Recommended Server |
P25215-AA1 HPE DL388 Gen10 8SFF |
P25216-AA1 HPE DL388 Gen10 8SFF |
P25217-AA1 HPE DL388 Gen10 8SFF |
Dell 2U R740 4210R/8G*1/600G SAS 10K*1/H330/DVD/750W*1/3.5-8 |
|
Processor |
Intel Xeon 3206R (8-Core, 1.9 GHz, 85W) |
Intel Xeon Silver 4210R Processor (2.4GHz/10-core/100W) |
Intel Xeon Silver 4214R Processor (2.4GHz/12-core/100W) |
Up to two 2nd Generation Intel Xeon Scalable processors, up to 28 cores per processor |
|
Memory |
16G |
16G |
16G |
24 DDR4 DIMM slots, Supports RDIMM /LRDIMM, speeds up to 2933MT/s, 3TB max Up to 12 NVDIMM, 192 GB Max Up to 12 Intel Optane DC persistent memory PMem, 6.14TB max (7.68TB max with PMem + LRDIMM) Supports registered ECC DDR4 DIMMs only |
|
Hard Drive |
8 SFF |
8 SFF |
8 SFF |
Front drive bays: Up to 16 x 2.5” SAS/SATA (HDD/SSD) max 122.88TB or up to 8 x 3.5” SAS/SATA HDD max 128TB Optional DVD-ROM, DVD+RW |
|
Power Supplies |
500W |
800W |
800W |
Titanium 750W, Platinum 495W 750W 750W 240VDC, 1100W, 1100W 380VDC 1600W, 2000W and 2400W, Gold 1100W -48VDC |
Get More Information
Please feel free to check the P25216-AA1 datasheet below.
Do you have any question about the Hpe Proliant DL388 Gen10 servers P25216-AA1 or P25216-AA1 price
Contact us now via Live Chat or [email protected].
P25216-AA1 HPE DL388 Gen10 8SFF Datasheet
P25216-AA1 Specification |
|
|
Model |
HPE Proliant DL388 G10 4210R (10-Core, 2.4 GHz, 100W) 1P 16G P408i-a NC 8SFF 800W PS server |
|
Processor |
Intel Xeon Silver 4210R Processor (2.4GHz/10-core/100W) |
|
Memory |
16G |
|
Array controller |
Built-in HPE Smart Array P408i-a/2GB SR Gen10 12Gb SAS array controller with intelligent storage battery |
|
PCIe slots |
3 |
|
Hard Drive |
Standard 8 SFF hot-plug hard disk slots, Expands up to 24+6 SFF hot-swappable drives, comes standard with no hard drives |
|
Power Supply |
800W |
|
Fan |
4 hot-swappable fans, up to 6 hot-swappable fans (N+1) |
|
Height |
2U |
