Product Model: N3224P-ON
Retail Price: US$5,648.00
Email Us To Get Special Price Today: [email protected]
The Dell N3224P-ON is a versatile and powerful networking switch designed to meet the needs of modern enterprise environments. Boasting 24x1G RJ-45 ports, 4x10G SFP+ ports, and 2x100G QSFP28 ports, it provides reliable and high-speed connectivity. With PoE 30W capabilities and 1xAC PSU, the switch combines performance and efficiency. The N3224P-ON operates on OS6, offering a plethora of features for robust network management.
Quick Spec
| Product Model | Dell N3224P-ON |
| Ports | 24x1G RJ-45, 4x10G SFP+ |
| Uplinks | 2x100G QSFP28 |
| Power over Ethernet | 30W per port |
| Power Supply | 1xAC PSU |
| Operating System | OS6 |
Product Datasheet
- 24x1G RJ-45 ports for versatile connectivity.
- 4x10G SFP+ ports for high-speed network uplinks.
- 2x100G QSFP28 ports for ultra-fast data transfer.
- 30W PoE support to power devices directly from the switch.
- Operates on OS6, providing advanced network management.
Product Applications
- Ideal for mid-sized enterprises requiring efficient network distribution and management.
- Perfect for environments with high data transfer needs, thanks to its 100G QSFP28 uplinks.
- Suitable for powering PoE-enabled devices like IP phones and cameras directly through the switch.
Supported Options
| Accessory | Model |
| Redundant Power Supply | Dell RPS720 |
| Transceiver Module | Dell SFP10G-SR |
| Mounting Kit | Dell MK120 |
Compare to Similar Items
| Model | Differences |
| Cisco C9200-24P | Fewer uplink options, different OS |
| HP Aruba 2930F | Lower PoE capabilities, fewer uplink interfaces |
| Juniper EX3300-24P | Lower overall throughput, fewer high-speed ports |
Before Purchasing
For further information about the Dell N3224P-ON and its pricing, please contact us through Live Chat or email us at [email protected].
Specification
N3224P-ON Datasheet
Dell N3224P-ON Specifications | |
| Brand | Dell |
| Model | N3224P-ON |
| Ports | 24x 1G RJ-45 |
| Uplink Ports | 4x 10G SFP+ |
| High-Speed Ports | 2x 100G QSFP28 |
| PoE | 30W |
| Power Supply | 1x AC PSU |
| Airflow Direction | IO to Power Supply (IO/PS) |
| Operating System | OS6 |
| Switching Capacity | 220 Gbps |
| Forwarding Rate | 164 Mpps |
| Rack Units | 1U |
| Max Power Consumption | 420W |
| Dimensions (HxWxD) | 44.0 mm x 440.0 mm x 387.4 mm |
| Redundant Power Supply | Optional |
| Management | Web-based |
| VLAN | Supported |
| Stacking | Stackable up to 12 units |
| Link Aggregation | Supported |
| Jumbo Frames | Supported (up to 9216 bytes) |
| MAC Address Table | 16,000 entries |
| IPv6 Support | Yes |
