Juniper EX4400-24P Switches Price & Product Datasheet

Product Model: Juniper EX4400-24P

Retail Price: US$3,700.00

Email Us To Get Special Price Today: [email protected]

24x1G POE switch with 2x100G uplink/stacking ports. 90W POE. MACsec AES256 capable (optional license sold separately). Optional extension module(sold separately): 4x10G or 4x25G

The EX4400 Ethernet Switch is a cloud-ready, AI-powered access switching platform with advanced security for high-performance campus deployments. Its differentiated by features such as Power over Ethernet (PoE, PoE++), MACsec AES-256, microsegmentation using group-based policies (GBP), EVPN-VXLAN to the access layer, and flow-based telemetry.

As part of the underlying infrastructure forJuniper Mist Wired Assurance, the EX4400 is easy to onboard, configure, and manage. TheJuniper Mist Cloudstreamlines deploying and managing your campus fabric, whileMist AIsimplifies operations and improves visibility into the performance of connected devices.

Key features of the EX4400 include:
Cloud-ready, driven by Mist AI with Juniper Mist Wired Assurance and Marvis Virtual Network Assistant
Ethernet VPN?CVirtual Extensible LAN (EVPN-VXLAN) to the access layer
End-to-end encryption using Media Access Control Security (MACsec) AES256
IEEE 802.3bt Power over Ethernet (PoE++)
Standards-based microsegmentation using group-based policies (GBP)
Flow-based telemetry to monitor traffic flows for anomaly detection
Precision Timing Protocol ?C Transparent clock
10-member Virtual Chassis support

Offering a full suite of Layer 2 and Layer 3 capabilities, the EX4400 enables a variety of deployments, including campus, branch, and data center top-of-rack deployments. As requirements grow, Junipers Virtual Chassis technology allows up to 10 EX4400 switches to be seamlessly interconnected and managed as a single device, delivering a scalable, payas-you-grow solution for expanding network environments.

Table 1 shows the EX4400 Line of Ethernet Switches.

Model	Access Port Configuration	PoE++ Ports	PoE++ Budget 1 PSU/2 PSU	10GbE Ports (max. with module)	25GbE Ports (max. with module)	100GbE ports	Power Supply Rating	Cooling
EX4400-48P	48-port 10/100/1000BASE-T	48	1290 W/ 1800 W	0(4)	0(4)	2	1600 W AC	AFO (Front-to-back airflow)
EX4400-24P	24-port 10/100/1000BASE-T	24	788 W/ 1440 W	0(4)	0(4)	2	1050 W AC	AFO (Front-to-back airflow)
EX4400-48T	48-port 10/100/1000BASE-T	0	N/A	0(4)	0(4)	2	550 W AC	AFO (Front-to-back airflow)
EX4400-24T	24-port 10/100/1000BASE-T	0	N/A	0(4)	0(4)	2	550 W AC	AFO (Front-to-back airflow)
EX4400-48F	12-port 1000/10000BASE-X + 36-port 100/1000BASE-X	0	N/A	12(16)	0(4)	2	550 W AC	AFO (Front-to-back airflow)

Quick Spec

Table 2 shows the quick spec.

Model	Juniper EX4400-24P
Form factor	Fixed 1 U access
Port density	EX4400-48F: 36 x 1GbE + 12 x 10GbE and 4 x 10/25GbE uplinks EX4400-24P/24T: 24 x 1GbE and 4 x 10/25GbE uplinks EX4400-48P/48T: 48 x 1GbE and 4 x 10/25GbE uplinks
Dimensions (W x H x D)	17.4 x 1.7 x 15.7 in (44.2 x 4.4 x 39.9 cm)
Data rate	EX4400-48F: 456/912 Gbps EX4400-24P/24T: 324/648 Gbps EX4400-48P/48T: 348/696 Gpbs
Throughput	EX4400-48F: 714 Mpps EX4400-24P/24T: 333 Mpps EX4400-48P/48T: 369 Mpps
Quality-of-service (QoS) queues/port	12 (8 unicast, 4 multicast)
Number of VLANs	4093
