Product Model: AR161FV-1P
Retail Price: US$0
Email Us To Get Special Price Now: [email protected]
Huawei next-generation voice router AR161FV-1P is designed for the enterprise branch or small business to deliver a comprehensive set of services which include routing, switching and voice function. The AR161FV-1PGW-La comes with fixed 1 * Combo WAN interface (SFP/RJ-45), 1 fixed voice port, 4 * 10/100 switching LAN interface, security functions, wireless AP management functionality all in one device. AR161FV-1PV is a mature, stable and quiet router and delivers the high performance functionality for small network which greatly increase productivity with lower the cost. the router is easy to deploy, configure and customize to greatly reduce the cost of deployment and maintenance.
Quick Specs
Figure 1 shows the appearance of Huawei Router – AR161FV-1P.
Table 1 shows the Quick Specs.
|
Product Code |
Huawei Router – AR161FV-1P |
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 ADSL-B/J interface LAN interfaces: 4 10/100M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: GE0-GE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8 kg (6.17 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
Product Details
Figure 2 shows the back panel of Huawei Router – AR161FV-1P.
Note:
|
① |
VE1 interface |
|
② |
CON/AUX interface |
|
③ |
WAN GE Combo interfaces |
|
④ |
4 FE electrical interfaces |
|
⑤ |
RST button |
|
⑥ |
Power interface |
|
⑦ |
Jack for power cable locking strap |
The Optical transceiver
Table 2 shows the recommended elements for the Huawei Router – AR161FV-1P.
|
Model |
Description |
|
FE-SFP Optical Transceiver |
|
|
SFP-FE-SX-MM1310 |
SFP,100M/155M,Multi-mode Module(1310nm,2km,LC) |
|
eSFP-FE-LX-SM1310 |
eSFP,100M/155M,Single-mode Module(1310nm,15km,LC) |
|
S-SFP-FE-LH40-SM1310 |
eSFP,FE,Single-mode Module(1310nm,40km,LC) |
|
GE-SFP Optical Transceiver |
|
|
SFP-1000BaseT |
SFP,GE,Electrical Interface Module(100m,RJ45) |
|
eSFP-GE-SX-MM850 |
eSFP,GE,Multi-mode Module(850nm,0.55km,LC) |
|
SFP-GE-LX-SM1310 |
eSFP,GE,Single-mode Module(1310nm,10km,LC) |
|
S-SFP-GE-LH40-SM1310 |
eSFP,GE,Single-mode Module(1310nm,40km,LC) |
|
S-SFP-GE-LH40-SM1550 |
eSFP,GE,Single-mode Module(1550nm,40km,LC) |
Compare to Similar Items
Table 3 shows the comparison between AR161FV-1P and AR2220E
|
Model |
AR161FV-1P |
AR2220E |
|
SIC Slots |
0 |
4 |
|
Memory |
512 MB |
1 GB |
|
Flash |
512 MB |
512 MB |
|
Weight |
2.8 kg (6.17 lb) |
6 kg (13.2 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
442.0 mm x 420.0 mm x 44.5 mm |
Get more information
Do you have any question about the AR161FV-1P
Contact us now via Live Chat or [email protected].
Specification
AR161FV-1P Datasheet
AR161FV-1P Specification |
|
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 ADSL-B/J interface LAN interfaces: 4 10/100M auto-sensing Ethernet electrical interfaces |
|
Extended slots |
Not supported |
|
Interface number |
LAN interfaces: GE0-GE3 |
|
Power module type |
External power adapter |
|
Weight |
2.8 kg (6.17 lb) |
|
Dimensions (W x D x H) |
300.0 mm x 216.4 mm x 44.0 mm |
