AirEngine 5760-51 – Huawei Indoor Access Points Product Price & Datasheet

Spread the love

Product Model: AirEngine 5760-51

Product Special Price: US$232.00

Email Us To Get Special Price Now: [email protected]

Specification

AirEngine 5760-51 Datasheet

AirEngine 5760-51 Specification
Dimensions (Diameter x Height)	220 mm x 50 mm
Power Input	DC: 48 V ± 10% PoE power supply: in compliance with IEEE 802.3bt
Maximum Number of Users	≤ 1024 (dual-radio mode) ≤ 1152 (triple-radio mode) Note: The actual number of users varies according to the environment.
Port	1 x 5 GE and 1 x GE electrical
IoT	Built-in IoT slots
Operating Temperature	–10°C to 50°C
Antenna Type	Built-in Smart Antennas
MIMO: Spatial Streams	Basic capability: 2.4 GHz: 2×2:2; 5 GHz: 4×4:4 2.4 GHz: 2×2:2; 5 GHz-0: 2×2:2; 5 GHz-1: 2×2:2 Capability upgrade via RTU license: 2.4 GHz: 4×4:4; 5 GHz: 4×4:4 2.4 GHz: 2×2:2; 5 GHz-0: 2×2:2; 5 GHz-1: 4×4:4
Radio Protocols	802.11a/b/g/n/ac/ac Wave 2/ax
Maximum Data Rate	Basic capability: up to 5.37 Gbit/s RTU license upgrade: up to 5.95 Gbit/s

Huawei AirEngine 5760-51 Access point provides Software-Defined Radio (SDR) and flexible switching between dual-radio and triple-radio modes and it is a next generation Wi-Fi 6 (802.11ax) indoor Access Point (AP) that excels at handling high performance and high-density scenarios.

Quick Spec

Table 1 shows the quick spec.

Model	AirEngine 5760-51
Power Input	DC: 48 V 10% PoE power supply: in compliance with IEEE 802.3bt
Maximum Number of Users	1024 (dual-radio mode) 1152 (triple-radio mode) Note: The actual number of users varies according to the environment.
Port	1 x 5 GE and 1 x GE electrical
IoT	Built-in IoT slots
Antenna Type	Built-in Smart Antennas
Radio Protocols	802.11a/b/g/n/ac/ac Wave 2/ax
Maximum Data Rate	Basic capability: up to 5.37 Gbit/s RTU license upgrade: up to 5.95 Gbit/s

Product Details

AirEngine 5760-51 provides these features:

Smart Antennas

Dual-band co-planar Smart Antennas suppress interference automatically, double signal strength, and provide 20% greater coverage distance, realizing high-quality wireless coverage with zero blind spots.

Software-Defined Radio

Flexibly switching between dual-radio and triple-radio modes improves concurrent capacity by 50%, with the ability to adapt to bandwidth-intensive and high-concurrency scenarios.

IoT Expansion

BLE 5.0 supported by default, with built-in, dual IoT slots and a USB port that adapt to multiple IoT protocols, such as RFID and ZigBee, meeting access requirements for a range of IoT terminals.

Compare to Similar Items

Table 2 shows the comparison.

Model	AirEngine 5760-51	AirEngine 5760-10
Power Input	DC: 48 V 10% PoE power supply: in compliance with IEEE 802.3bt	DC: 12 V 10% PoE: In compliance with IEEE 802.3at
Maximum Number of Users	1024 (dual-radio mode) 1152 (triple-radio mode) Note: The actual number of users varies according to the environment.	512 Note: The actual number of users varies according to the environment.
Antenna Type	Built-in Smart Antennas	Built-in smart antennas
Radio Protocols	802.11a/b/g/n/ac/ac Wave 2/ax	802.11a/b/g/n/ac/ac Wave 2/11ax
Maximum Data Rate	Basic capability: up to 5.37 Gbit/s RTU license upgrade: up to 5.95 Gbit/s	1.775 Gbit/s
