Product Model: 845806-375
Retail Price: US$2,426.75
Email Us To Get Special Price Today: [email protected]
845806-375 is the HPE ProLiant DL380 Gen9 E5-2630v4 – 8SFF Server, with Intel? Xeon? E5-2630v4 (2.2GHz/10-core/25MB/85W), HPE 1Gb Ethernet 4-port 331i, P440ar/2GB, one HPE 500W power supply, iLO Management, Intelligent Provisioning, 2U Rack, HPE Easy Install Rails, and Warranty 3y, 24×7.
Quick Spec
Table 1 shows the quick spec.
|
Product Model |
845806-375 |
|
Processor |
Intel? Xeon? E5-2630v4 (2.2GHz/10-core/25MB/85W) |
|
Number of processors |
1 |
|
Processor core available |
10 |
|
Processor cache |
25MB |
|
Processor speed |
2.2GHz |
|
Form factor (fully configured) |
2U |
|
Product dimensions (H x W x D) |
3.44 x 17.54 x 26.75 in (8.73 x 44.55 x 67.94 cm) |
|
Weight |
Minimum – 8SFF chassis with 1xSFF HDD and 7 HDD blanks, 1x processor, 1x power supply (plus blank), 1x Flexible Smart Array, 1x Riser installed: 32.6 lb (14.759 kg) Maximum – 12 LFF hard drives (No rear drives), 2x processors, 2x power supplies, 1x Flexible Smart Array, 2x Risers installed): 51.5 lb (23.6 kg) |
Product Details
Figure 1 shows the Front View – 8SFF Chassis with Optional Universal Media Bay shown.
Note:
|
① |
Quick removal access panel |
|
② |
Bay 1 |
|
③ |
Bay 2 |
|
④ |
Bay 3 |
|
⑤ |
Power On/Standby button and system power LED button |
|
⑥ |
Health LED |
|
⑦ |
NIC status |
|
⑧ |
UID button |
|
⑨ |
USB 3.0 |
|
⑩ |
Serial label pull tag |
|
? |
8 SFF Drive Cage Bay |
|
? |
Drive Bay 2. Blank shown, 8SFF or 6NVMe optional |
|
? |
Optional 2 SFF HDD, blank shown. Requires Universal Media bay |
|
? |
Optional Optical drive. Requires Universal Media bay |
Figure 2 shows the Rear View.
Note:
|
① |
PCI Slots (Slots 1-3 top to bottom, riser shipped standard) |
|
② |
PCI Slots (Slots 4-6top to bottom, requires second riser card, and second processor) |
|
③ |
Optional serial port |
|
④ |
Optional rear 2 SFF HDD (supported in 24 SFF or 12 LFF front end) |
|
⑤ |
Power supply Power connection |
|
⑥ |
Power supply Power LED |
|
⑦ |
HPE Flexible Slot Power Supply bay 2 (800w shown) |
|
⑧ |
Power supply Power connection |
|
⑨ |
Power supply Power LED |
|
⑩ |
HPE Flexible Slot Power Supply bay 1 (800w shown) |
|
? |
VGA connector |
|
? |
Embedded 4x1GbE Network Adapter |
|
? |
USB 3.0 connectors (2) |
|
? |
Unit ID LED |
|
? |
Optional FlexibleLOM ports (Shown: 4x1GbE) |
The Accessories
Table 2 shows the recommended elements.
|
Product number |
Description |
|
872475-B21 |
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
872477-B21 |
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
870753-B21 |
HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
872479-B21 |
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
868818-B21 |
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
|
875503-B21 |
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD |
Compare to Similar Items
Table 3 shows the comparison.
|
Product Model |
845806-375 |
793308-B21 |
|
Number of processors |
1 |
2 |
|
Processor core available |
10 |
8 |
|
Processor cache |
25MB |
20MB L3 |
|
Processor speed |
2.2GHz |
2.0GHz |
Get More Information
Do you have any question about the 845806-375
Contact us now via Live Chat or [email protected].
845806-375 Datasheet
HPE 845806-375 Specification |
|
|
Processor |
Intel® Xeon® E5-2630v4 (2.2GHz/10-core/25MB/85W) |
|
Number of processors |
1 |
|
Processor core available |
10 |
|
Processor cache |
25MB |
|
Processor speed |
2.2GHz |
|
Form factor (fully configured) |
2U |
|
Form factor chassis |
|
|
Power supply type |
|
|
Network controller |
|
|
Storage controller |
|
|
Product dimensions (H x W x D) |
3.44 x 17.54 x 26.75 in (8.73 x 44.55 x 67.94 cm) |
|
Weight |
Minimum – 8SFF chassis with 1xSFF HDD and 7 HDD blanks, 1x processor, 1x power supply (plus blank), 1x Flexible Smart Array, 1x Riser installed: 32.6 lb (14.759 kg) Maximum – 12 LFF hard drives (No rear drives), 2x processors, 2x power supplies, 1x Flexible Smart Array, 2x Risers installed): 51.5 lb (23.6 kg) |
